J anchor bolt
J- Shaped Bolt Anchor Bolt
Product Sheet TABLE
j anchor bolt (J Type Anchor Bolt)
J Anchor Bolt is a crucial product for construction and industrial applications, providing a reliable and sturdy connection between different parts of a structure. This product is designed with a J-shaped end that is embedded into a concrete foundation, providing a strong and secure anchor point for the structure. With J Type Anchor Bolt, you can easily install your structures without requiring specialized skills, while also improving their overall stability and safety. Moreover, this product is highly resistant to environmental factors, such as corrosion and weathering. Overall, J Anchor Bolt is one of the best solutions available for enhancing the strength and stability of construction structures. Visit our website to learn more about J Anchor Bolt and order this high-quality product today.
The best seller in the field of J-anchor bolt production
Product Name |
|---|
MATERIAL l bolts |
STANDARD |
GRADE |
Type of Thread |
Threaded Section |
l anchor bolt sizes |
Diameter Tolerance |
Length |
Bend Length |
Finish |
Added Services |
PACKAGING |
Term |
j shape / anchor bolt |
|---|
Carbon Steel |
DIN-ASTM-ANSI-BSW-JIS-AISI-GB |
4.8 – 5.8 – 6.8 – 8.8 – 10.9 – 12.9 |
Millimeter – Inch , …. |
Base on your order |
(M12-M100) – (3/16”-4”) |
± 0.05 mm |
140 mm – 3000 mm |
up to customer request |
Plain,bulk, ZincPlated(Clear/Blue/Yellow),
black oxide, H.D.G, DAC,GOEMET |
– |
pallet ,Based on Customer’s request |
EXWORK – FOB – C&F – CIP ,… |
Product details
The process for creating a J-shaped anchor bolt, the manufacturing process typically involves the following steps: 1- cutting the steel rod 2- Bending the end 3- Threading the other end 4-Heat treating (optional) 5- Galvanizing or coating 6- Quality control.
A J-shaped anchor bolt is a type of fastener that is used to secure objects or structures to a concrete or masonry surface. The bolt is typically made of high-strength steel and is embedded into the concrete or masonry during construction. The J-shape of the bolt allows for greater flexibility in anchoring objects and structures to the surface.
The J-shaped anchor bolt is similar to an L-shaped anchor bolt, but with a curved end instead of a bent end. The J-shape allows for greater flexibility in attachment and can be used in applications where the angle of the attachment needs to be adjusted.
Anchor bolts are commonly used in the construction of buildings, bridges, and other structures to provide a secure connection between the structure and the foundation. They are also used in the
installation of heavy machinery and equipment, as well as in the installation of fences, guardrails, and other types of barriers.
